Right Results.
Right Away.
Unifying both composite micromechanical and structural modeling.
Efficient. Accurate. Versatile.
Model advanced materials and structures as easily as metals through a revolutionary approach, including composites, tailorable composites, metamaterials, hybrid material systems, architected materials, porous materials, and many more). We have two tools, SwiftComp and VABS. SwiftComp enables an unprecedented combination of efficiency and accuracy in multiphysics modeling. SwiftComp quickly and accurately calculates the effective material and inertial properties of advanced materials which can be used as inputs for structural solvers. VABS is a cross sectional analysis tool for composite slender structures, particularly blades (helicopter, wind turbine, air mobility, propellers, etc.). The programs have helped engineers at numerous companies, national labs (NREL, SNL, INL), government agencies, and universities consider more design options and arrive at the best solution more quickly. By using effective properties, users are also able to accurately handle more challenging problems, often ones that are too computationally intensive using other approaches. Analysis time is typically reduced from several hours to just seconds with 3D FEA-level accuracy (on minimal computing power).
Unifying composite micromechanical and structural modeling
—
SwiftComp is a general-purpose multiscale constitutive modeling code for unified modeling of composites beam, plates/shells, or 3D structures. It can quickly and easily calculate all the effective properties for a wide variety of composites, computing the best structural model for use in macroscopic structural analysis, as well as dehomogenization.
RIGOROUS MODELING OF COMPOSITE BEAMS AND BLADES
—
VABS is a popular general-purpose cross-sectional analysis tool for quickly and easily computing beam properties and recovering 3D fields of composite beams, including helicopter and wind turbine blades. It is the only tool capable of rigorously decoupling an original 3D slender solid with complex microstructure into a simple engineering beam model.
Right Results. Right Away.
Even for complex composites, AnalySwift’s uniquely powerful approach delivers the accuracy of detailed 3D FEA at the efficiency of simple engineering models, reducing early stage analysis time from hours to seconds.
Efficient.
Accurate.
Versatile.
300x Faster
than 3D FEA for realistic rotor blade
2,000x Faster
than 3D FEA for 4 layer cross-ply laminate
Industries
AnalySwift products for efficient, high-fidelity composite modeling enable solutions in an wide variety of industries. In addition to traditionally composite-heavy industries, applications are also found in life sciences and other industries exploring complex heterogeneous materials and structures. Please contact us today for a free trial version of SwiftComp or VABS.
Applications
AnalySwift’s software handles a wide variety of 1D, 2D, and 3D composite structures, enabling the virtual testing of composites for mechanical and multifunctional properties.
MULTISCALE MODELING OF COMPOSITES
3D composite structures
- Binary composites
- Fiber reinforced composites
- Particle reinforced composites
- Textile composites
- Short fiber composites
- Porous materials
- Foams
- Other heterogeneous materials
2D Composite plates/shells
- Laminates
- Stiffened panels
- Corrugated structures
- Perforated structures
- Sandwich structures
- Unitized structures
- And more
1D Composite beams
- Helicopter rotor blades
- Wind turbine blades
- Propellers
- High-aspect wings
- Golf clubs
- Fishing rod
- And other slender composites structures
VIRTUAL TESTING OF COMPOSITES
Mechanical properties
- Elastic constants
- Static strength
Multiphysical properties
- Conductivities
- Dielectric
- Magnetic
- Diffusive properties
- Coefficients of thermal expansion and specific heat
- Electromagnetic properties
